Auto focus control via EtherCAT, Profinet, 0-10V or Pulse.

4 cover glasses to further secure the dust protection.

Real-time status of cutting head could be accessed at mobile APP or CNC controller.

Real-time detection to focus position and ready status of bottom cover glass.

Real-time detection to temperature of top/bottom cover glass and focus lens.

Real-time detection to stray beam to improve the detection sensitivity of optics contamination while nitrogen cutting.

Real-time detection and closed loop control to cutting gas pressure.

Real-time detection to temperature of dew point.

Real-time detection to cavity pressure.

Real-time detection to temperature of TRA (nozzle assembly) to secure stable capacitance for proper height follow and cutting.

Anti-collision protection of TRA (nozzle assembly).

Nozzle cooling by gas to improve cutting capacity.

Built-in amplifier design to help improve capacitance stability and decline interference.

Smart detection of piercing to shorten cycle time from piercing to cutting without delay and extend lifespan of bottom cover glass.

Smart detection of cutting process to repeat cutting once the material is not cut through to secure consistency of cutting and decline material waste.

Real time detection of co-edge of sheet metal to determine if to activate piercing or not based on alignment condition.

Standard QD/LOE/Q+ interfaces to work with different fiber lasers.
